180/180 Gallon Complete Gravity Feed Tank System Rhino Tuff Tanks (MPN: RTT-6880)

Description

The Rhino 180/180 Gallon Gravity Feed Tank System combines two 180-gallon tanks to provide a substantial 360-gallon fluid storage capacity in a compact, stackable design. This system is engineered for efficient gravity-fed dispensing, making it ideal for agricultural, commercial, and industrial fluid management applications.

Constructed from natural virgin high-density polyethylene (HDPE), the tanks offer excellent chemical resistance and durability. The system features brass spring valves, a drip tray kit, and a sturdy 24" leg tank stand to support safe and reliable dispensing. Molded-in brass inserts enable easy mounting of pump plates, while integrated site gauges provide clear fluid level visibility.

Key Features

• 360-Gallon Capacity: Two 180-gallon stackable tanks combined.
• Complete Kit: Includes tank stand with 24" legs, drip tray kit, brass spring valves, and accessory package.
• Stackable Design: Interlocking molded ridges for stable stacking without adapters.
• Multiple Openings: 2" top opening for pump or vent, 1" port for desiccant breather or remote fill, and 2" center fill.
• Pump Mounting: Six molded-in brass inserts for attaching side pump plates.
• Exclusive Drain: Molded-in 1" NPT brass bushing for efficient drainage.
• Visual Monitoring: Molded-in site gauge with semi-transparent tank walls for accurate fluid level viewing.
• Durable Material: Made from natural virgin HDPE to resist cracking and corrosion.
• Standard Footprint: 3' x 3' footprint compatible with all Rhino Tuff Tanks.


Specifications

• Model: RTT-6880
• Manufacturer: Rhino Tuff Tanks
• Capacity: 360 Gallons (2 x 180 Gallon Tanks)
• Assembled Dimensions: 36" L x 42" W x 107" H
• Material: Natural virgin HDPE
• Top Openings: 2" for pump or vent
• Additional Ports: 1" for desiccant breather or remote fill, 2" center fill
• Drain Port: Molded-in 1" NPT brass bushing
• Pump Mounting: Six molded-in brass inserts
• Site Gauge: Molded-in, semi-transparent
• Footprint: Standard 3' x 3'
• Stackable: Yes, in any combination with other Rhino tanks


Documents

Gravity Feed System Assembly Instructions

Gravity Feed System Assembly Video

Shipping & Warranty

This product ships via LTL freight with secure packaging. Liftgate service is available upon request during checkout to facilitate unloading when no forklift or dock is present.

Covered by a 1-Year Limited Warranty against defects in material and workmanship under normal usage conditions. The warranty excludes damage caused by misuse, improper installation, unauthorized modifications, neglect, or accidents.
